ACDelco GM Original Equipment Oil Filter
OE

ACDelco GM Original Equipment Oil Filter

GM Part #12737086

ACDelco Part #PF48

MSRP$10.76*

InstallationACDelco GM Original Equipment Engine Oil Filters are designed, engineered, and tested to rigorous standards, and are backed by General Motors.

  • InstallationACDelco filters use a blended media, including cellulose, polyester, and microglass for optimal efficiency and greater dirt-holding capacityInstallation
  • Nylon poppet style bypass valve in rear for today's high flow engines
  • The ACDelco Standard filter has 10 times more open area in the core for improved flow

About this product

InstallationACDelco GM Original Equipment Engine Oil Filters are designed, engineered, and tested to rigorous standards, and are backed by General Motors. These engine oil filters trap debris and other contaminants before they enter the engine lubrication system. ACDelco GM Original Equipment parts are the true OE parts installed during the production of or validated by General Motors for GM vehicles. Some ACDelco GM Original Equipment parts may have formerly appeared as GM Genuine Parts (OE) or ACDelco Professional.Installation

Warning WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

  • InstallationACDelco filters use a blended media, including cellulose, polyester, and microglass for optimal efficiency and greater dirt-holding capacityInstallation
  • Nylon poppet style bypass valve in rear for today's high flow engines
  • The ACDelco Standard filter has 10 times more open area in the core for improved flow
  • Improved filter cleanliness increased filter test life
  • Some ACDelco GM Original Equipment parts may have formerly appeared as GM Genuine Parts (OE) or ACDelco Professional
  • InstallationACDelco GM Original Equipment parts are designed, engineered and tested to rigorous standards, and are backed by General Motors. Installation
  • InstallationGM engineers design and validate OE parts specifically for your Chevrolet, Buick, GMC, or Cadillac vehicleInstallation
  • GM regularly updates production and service part designs to integrate new materials and technologies

Outer Diameter Bottom2.9 in / 74.3 mm
Gasket TypeGasket
Height33.11 in / 79 mm
ClassificationOE
Gasket Thickness0.27 in / 7 mm
Burst Pressure253
Gasket Inside Diameter2.38 in / 60.7 mm
Bypass Relief ValveYes
Anti-Drain Back ValveYes
Non Slip GripYes
Housing ColorBlue
Micron Rating30
Filter TypeCanister
Torque NutNo
Outside Diameter Top3.03 in / 77 mm
Gasket MaterialRubber
Gasket Outside Diameter2.57 in / 65.5 mm
Marine ApprovedNo
Universal Or Specific FitSpecific
Gasket Or Seal IncludedYes
Inside Diameter Top0.86 in / 22 mm
Flow Rate13.2 gal (US)/min / 729.51 gph

24 Months/Unlimited Miles Limited Warranty for Parts (plus Labor if installed by a GM dealer)

Please visit our warranty page on Gmparts.com for full warranty details.

ModelBody StyleTrimYear(s)
AllureCX, CXL, CXS2008, 2009, 2010
Enclave2008, 2009, 2010
LaCrosseCX, CXL2008, 2009, 2010
Rainier2007
